Medium and high pressure air compressors refer to equipment that can compress air to medium or high pressure. Usually, multi-stage compression is used to gradually increase the air pressure through multiple cylinders. The pressure range of 30-40 bar belongs to the medium and high pressure category. This type of compressor is usually used in industrial applications that require higher pressure, such as PET bottle production, blow molding, beverage packaging, etc.
Product features
● Air-cooling,low rotation speed,durable.
● High-efficiency valve assembly.
● Integrated crankcase.
● High-quality imported bearings.
● Compact,large-area intercooling and aftercooling.
Technical Parameters
Model | Air delivery (m³/min) | Working pressure (bar) | Motor power (kW) | Speed (rpm) | Dimensions L*W*H(mm) | Weight (Kg) |
RKA-1.0/30 | 1.0 | 30 | 11 | 620 | 1560*840*1140 | 430 |
RKA-1.0/30(T) | 1.0 | 30 | 11 | 620 | 2115*795*1135 | 530 |
RKA-1.2/30 | 1.2 | 30 | 15 | 760 | 1560*840*1140 | 450 |
RKA-1.2/30(T) | 1.2 | 30 | 15 | 760 | 2115*795*1135 | 550 |
RKA-1.6/30 | 1.6 | 30 | 18.5 | 790 | 1600*960*1230 | 520 |
RKA-1.6/30(T) | 1.6 | 30 | 18.5 | 790 | 2150*900*1230 | 620 |
RKA-2.0/30 | 2.0 | 30 | 22 | 735 | 2000*1010*1260 | 550 |
RKA-2.4/30 | 2.4 | 30 | 2x15 | 760 | 1930*1610*1100 | 900 |
RKA-3.2/30 | 3.2 | 30 | 2x18.5 | 790 | 2100*1700*1320 | 1150 |
RKA-4.0/30 | 4.0 | 30 | 2x22 | 735 | 2260*1650*1240 | 1200 |
Application Industry
Widely used in biology, chemical industry, pressure testing, ships, especially in hydropower stations, PET bottle blowing and blow molding machines, leak detection gas sources, military supporting and other fields.
Frequently Asked Questions
Q1. How long is the delivery time ?
A: For standard voltage ,15 working days. Non-standard ,please contact our sales.
Q2. What's payment term ?
A: T/T, L/C, D/P, Western Union, Paypal, Credit Card, and etc. Also we could accept USD, RMB, Euro and other currency.
Q3. How about your after-sales service ?
A: 1.Provide customers with installation and commissioning online instructions.
2. Well-trained engineers available to overseas service.
3.Worldwide agents and after service avaiable.arrange our engineers to help you training and installation.
Q4. How about your warranty?
A: One year for the whole machine and two years for screw air end, except consumable spare parts.
Q5. Do you have any certificate ?
A: Yes, per different customer's market need ,we can offer CE ,ISO etc certificate.
Q6. Do you offer OEM service ?
A: Yes.Both OEM & ODM service can be accepted.
