Product Features
1. Full Automation All systems are designed for un-attended operation and automatic Oxygen demand adjustment.
2. Lower Space Requirement The design and Instrumentation makes the plant size very compact, assembly on skids, prefabricated and supplied from factory.
3. Fast Start-up Start-up time is about 30 minutes to get desired Oxygen purity. So these units can be switched ON & OFF as per Oxygen demand changes.
4. High Reliability It's very reliable for continuous and steady operation with constant Oxygen purity. Plant availability time is better than 93% always.
5. Zeolite Molecular Sieves Life Expected Zeolite Molecular Sieves life is more than 10-years i.e. whole life time of Oxygen plant. So no replacement costs.
6. Low investment and energy consumption
7. Simple operation and maintenance.
Technical Parameters
| Model | RK/CMS-21/59 |
| Nitrogen production | 21Nm3/h |
| Nitrogen purity | 100.00% |
| Nitrogen pressure | 6bar |
| Nitrogen dew point | -40ºC |
| Generator power | 0.1kw |
| Controll method | PLC Controller |
| Air buffer tank | equipped with 1 pcs of 0.3m3 |
| Nitrogen buffer tank | equipped with 1 pcs of 0.3m3 |
| Dust filter | equipped with 1 pcs |
| Inlet size | DN15 |
| Outlet Size | DN25 |
| Dimension | 1700*1550*2000mm |
| Weight | 1100kg |
| Required compressed air | |
| Inlet air flow | ≥2.75m³/min |
| Inlet air pressure | ≥8 bar |
| Inlet air oil content | 0.01ppm |
Application Industry
1. Chemical and Petroleum Industry
Inerting: Nitrogen is used to prevent explosions in flammable liquid storage tanks and reactors (e.g., in petrochemical and coal chemical industries).
Pipeline Purging: Nitrogen is used to displace oxygen before transporting flammable media to prevent explosions.
Synthesis Gas Generation: Used as a feed gas or carrier gas in chemical reactions (e.g., ammonia synthesis).
2. Electronics Industry
Semiconductor Manufacturing: High-purity nitrogen (99.999%) is used to prevent oxidation during wafer production and packaging.
LED/LCD Screens: Provide an inert environment during annealing and welding.
3. Food and Beverages
Nitrogen Preservation: Used to package potato chips, milk powder, etc. to inhibit oxidation and extend shelf life (as an alternative to preservatives).
Beer Brewing: Nitrogen is used to purge oxygen before canning to maintain flavor.
4. Metal Processing
Heat Treatment: Nitrogen is used to prevent oxidation of metals (e.g., stainless steel and aluminum alloys) during annealing and quenching.
Laser Cutting: Nitrogen is used as an assist gas to prevent oxidation at the cut edge.
5. Pharmaceuticals and Biology
Drug Manufacturing: Inert storage of biologics and vaccines (e.g., freeze-dried powder injections).
Medical Equipment: High-purity nitrogen for cooling systems in equipment such as MRIs.
6. Other Industries
Tire Nitrogen Filling: Improves tire stability and reduces the risk of blowouts.
Fire Protection Systems: Nitrogen fire extinguishing in data centers and other locations (no residue).
FAQ
PSA Nitrogen/Oxygen Cylinder Filling System
Do not hesitate to send us mail with the following data.
1. N2 flow rate: _____Nm3/hr
2. N2 purity: _____%
3. N2 discharge pressure: _____Bar (150Bar or 200Bar)
4. N2 dew point: ______ ºC
5. Voltages and Frequency: ______V/PH/HZ
6. Local onsite altitude: ______ Meters above sea
7. N2 Application ______
8. Gas using: continuous or interrupt ? 24H/Day?
