Product features
1. Energy saving. Aluminum alloy three-in-one heat exchanger design, under the same processing capacity, the total input power is reduced by 15-50%.
2. High efficiency. Guide fins are added to the integrated heat exchanger to make the compressed air uniform inside
3. Intelligent. Multi-channel temperature and pressure monitoring, real-time display of dew point temperature, self-diagnosis function, automatic protection of equipment.
4. Environmental protection. This series of models all use R134a and R410a environmentally friendly refrigerants, and the degree of damage to the atmosphere is zero.
5. Stable. Standard constant pressure expansion valve, intelligent temperature control, stable operation even when the intake air temperature reaches 65°C and the ambient temperature reaches 42°C.
Technical Parameters
| Model | TR15 | TR20 | TR25 | TR30 | TR40 | TR50 | TR60 | TR80 | TR100 | TR120 | |
| Capacity | m3/min | 17 | 23 | 27 | 33 | 42 | 55 | 65 | 85 | 110 | 130 |
| Power supply | 380V 3PH 50HZ/60HZ | ||||||||||
| Input power | kW | 3.7 | 4.9 | 5.8 | 6.1 | 8 | 9.2 | 10.1 | 12 | 18.7 | 22.8 |
| Air pipe connection | DN50 | DN65 | DN80 | DN80 | DN100 | DN100 | DN100 | DN125 | DN150 | DN150 | |
| Evaporator type | Aluminum alloy plate | ||||||||||
| Refrigerant model | R407C | ||||||||||
| Display | LED dew point display, LED alarm code display, operation status indication | ||||||||||
| Anti-freezing protection | Constant pressure expansion valve & compressor automatic start /stop | ||||||||||
| Temperature control | Automatic control of condensing temperature / dew point temperature | ||||||||||
| High voltage protection | Temperature sensor&lnductive intelligent protection | ||||||||||
| Low voltage protection | Temperature sensor&lnductive intelligent protection | ||||||||||
| Weight | Kg | 180 | 210 | 350 | 420 | 550 | 680 | 780 | 920 | 1060 | 1200 |
| Dimension | L | 1000 | 1200 | 1200 | 1450 | 1450 | 1600 | 1650 | 1850 | 2280 | 2100 |
| W | 850 | 900 | 950 | 1000 | 1100 | 1200 | 1200 | 1350 | 1800 | 1900 | |
| H | 1143 | 1203 | 1273 | 1523 | 1683 | 1700 | 1700 | 1850 | 1960 | 2000 | |
Application Industry
Refrigerated air dryers cool compressed air to below its dew point, removing moisture from it. They are widely used in industries requiring high air dryness. Key applications include manufacturing, automotive painting, pneumatic tools, automated production lines, semiconductors, food packaging, pneumatic conveying, mixing, pharmaceuticals and healthcare, chemicals and energy, textiles, power generation, mining and construction, and transportation.
FAQ
Q1. What's payment term ?
A: T/T, L/C, D/P, Western Union, Paypal, Credit Card, and etc. Also we could accept USD, RMB, Euro and other currency.
Q2. How about your after-sales service ?
A: 1.Provide customers with installation and commissioning online instructions.
2. Well-trained engineers available to overseas service.
3.Worldwide agents and after service avaiable.arrange our engineers to help you training and installation.
Q3. How about your warranty?
A: One year for the whole machine and two years for screw air end, except consumable spare parts.
Q4. Do you have any certificate ?
A: Yes, per different customer's market need ,we can offer CE ,ISO etc certificate.
Q5. Do you offer OEM service ?
A: Yes.Both OEM & ODM service can be accepted.
