Medium and high pressure air compressors refer to equipment that can compress air to medium or high pressure. Usually, multi-stage compression is used to gradually increase the air pressure through multiple cylinders. The pressure range of 30-40 bar belongs to the medium and high pressure category. This type of compressor is usually used in industrial applications that require higher pressure, such as PET bottle production, blow molding, beverage packaging, etc.
1. High energy efficiencyLong component life, low wear and low speed: 340 rpm to 580 rpm, few wearing parts, easy accessto the machine for maintenance.
2.High reliability and easy maintenance.
3. Short maintenance time and good results.
4. Due to the use of anti-vibration devices, there is no need to lay a special foundation, and theinstallation is simple and fast, it can reduce the investment cost of installation.
| Model | Air delivery (m³/min) | Working Pressure (Bar) | Motor Power (kW) | Speed (RPM) | Dimension (mm) | Weight （kg） | ||||||||||||||||||||||||
| RKL-8.5/40 | 8.5 | 40 | 90 | 450 | 4050*1750*2380 | 5500 | ||||||||||||||||||||||||
| RKL-10/40 | 10 | 40 | 110 | 500 | 4050*1750*2380 | 5800 | ||||||||||||||||||||||||
| RKL-12/40 | 12 | 40 | 132 | 580 | 4050*1750*2380 | 6000 | ||||||||||||||||||||||||
| RKL-16/40 | 16 | 40 | 160 | 390 | 4650*2200*2780 | 7400 | ||||||||||||||||||||||||
| RKL-18/40 | 18 | 40 | 185 | 440 | 4650*2200*2780 | 7600 | ||||||||||||||||||||||||
| RKL-20/40 | 20 | 40 | 200 | 470 | 4650*2200*2780 | 7800 | ||||||||||||||||||||||||
| RKL-22/40 | 22 | 40 | 220 | 500 | 4650×2200*2780 | 8000 | ||||||||||||||||||||||||
| RKL-25/40 | 25 | 40 | 250 | 390 | 4950*2690*2980 | 8500 | ||||||||||||||||||||||||
| RKL-28/40 | 28 | 40 | 280 | 440 | 4950*2690*2980 | 8800 | ||||||||||||||||||||||||
| RKL-30/40 | 30 | 40 | 315 | 470 | 4950*2690*2980 | 9000 | ||||||||||||||||||||||||
1. PET Bottle Manufacturing
The primary application. Provides high-pressure, oil-free compressed air for blowing PET preforms into finished bottles used for Water bottles, Carbonated soft drinks, Juice and beverage containers
Edible oil bottles,Personal care and cosmetic packaging.
2. Blow Molding Industry
Supplies stable medium-pressure air for Injection blow molding (IBM), Extrusion blow molding (EBM), Stretch blow molding (SBM).
3. Food & Beverage Packaging
Ensures clean, contaminant-free air for packaging lines where hygiene and product safety are critical.
4. Pharmaceutical & Medical Packaging
Used in the production of medical-grade bottles and containers requiring high air purity standards.
5. Automotive Industry
Supplies compressed air for Pneumatic systems, Painting and coating applications, Component cleaning.
6. General Industrial Manufacturing
Provides reliable compressed air for Pneumatic tools, Automation equipment, Material conveying systems.
Q1. How long is the delivery time ?
A: For standard voltage ,15 working days. Non-standard ,please contact our sales.
Q2. What's payment term ?
A: T/T, L/C, D/P, Western Union, Paypal, Credit Card, and etc. Also we could accept USD, RMB, Euro and other currency.
Q3. How about your after-sales service ?
A: 1.Provide customers with installation and commissioning online instructions.
2. Well-trained engineers available to overseas service.
3.Worldwide agents and after service avaiable.arrange our engineers to help you training and installation.
Q4. How about your warranty?
A: One year for the whole machine and two years for screw air end, except consumable spare parts.
Q5. Do you have any certificate ?
A: Yes, per different customer's market need ,we can offer CE ,ISO etc certificate.
Q6. Do you offer OEM service ?
A: Yes.Both OEM & ODM service can be accepted.
