Compared with traditional compressors, oil-free scroll compressors have excellent performances such as novel structure, compact size, light weight, low noise, long life and low maintenance cost. Known as "maintenance-free air compressor", it is an ideal model for air compressors below 50HP.
Product Parameters
| Oil free scroll air compressor | |||||||||
| Model | Air Delivery(m3/min) | Power (kW) | Air-end | Air tank | Noise dB(A) | Outlet diameter | Dimension (mm) | Weight (Kg) | |
| 8bar | 10bar | Power*Qty | Liters | L * W * H | |||||
| RO-2.2AT | 0.24 | 0.22 | 2.2 | 2.2*1 | 40 | 55 | G1/2 | 700*500*1220 | 160 |
| RO-3.7AT | 0.40 | 0.34 | 3.7 | 3.7*1 | 40 | 55 | G1/2 | 700*500*1220 | 170 |
| RO-2.2A | 0.24 | 0.22 | 2.2 | 2.2*1 | / | 55 | G1/2 | 650*500*870 | 125 |
| RO-3.7A | 0.40 | 0.34 | 3.7 | 3.7*1 | / | 55 | G1/2 | 650*500*870 | 135 |
| RO-5.5A | 0.60 | 0.55 | 5.5 | 5.5*1 | / | 55 | G1/2 | 790*640*1050 | 190 |
| RO-7.5A | 0.80 | 0.68 | 7.4 | 3.7*2 | / | 60 | G1/2 | 980*675*1270 | 350 |
| RO-11A | 1.20 | 1.10 | 11 | 5.5*2 | / | 60 | G3/4 | 852*1274*1330 | 450 |
| RO-15A | 1.60 | 1.36 | 14.8 | 3.7*4 | / | 63 | G1 1/2 | 1565*1274*1330 | 700 |
| RO-16.5A | 1.80 | 1.65 | 16.5 | 5.5*3 | / | 63 | G1 1/2 | 1565*1274*1330 | 710 |
| RO-22A | 2.40 | 2.20 | 22 | 5.5*4 | / | 63 | G1 1/2 | 1565*1274*1330 | 730 |
| RO-33A | 3.60 | 3.30 | 33 | 5.5*6 | / | 65 | G1 1/2 | 1565*1274*1775 | 1020 |
| RO-44A | 4.80 | 4.40 | 44 | 5.5*8 | / | 68 | G1 1/2 | 1565*1274*1775 | 1250 |
Product features
Oil free
The compressed air is clean and oil-free, and the product has obtained the 0-level oil-free certificate certified by the German TUV certification agency.
Low vibration
When rotating, the high pressure area around the axis is evenly distributed, without eccentricity, good balance and small vibration.
Low noise
There are very few parts, there is almost no part collision sound, and the noise is extremely low.
High efficiency
Unique vortex structure, high volume ratio, no energy waste, higher efficiency.
High reliability
The processing accuracy can reach micron level, and the heat dissipation design makes the air compressor more reliable.
Low maintenance
There are almost no wearing parts and the maintenance cost is extremely low.
Application Industry
Oil-free scroll air compressors are widely used in electronics, food, medicine, dentistry, golf courses, fermentation, textile, chemical and other industries.
