PET high-pressure blow molding air compressor is a high-pressure air supply equipment designed specifically for PET (polyethylene terephthalate) plastic bottle blow molding. It provides stable, clean high-pressure air (usually 25-40Bar) for heating the preform and then blowing it into shape.
Product Parameters
| Model | Air delivery (m³/min) | Working Pressure (Bar) | Motor Power (kW) | Speed (RPM) | Dimension (mm) | Weight （kg） | ||||||||||||||||||||||||
| RKL-8.5/40 | 8.5 | 40 | 90 | 450 | 4050*1750*2380 | 5500 | ||||||||||||||||||||||||
| RKL-10/40 | 10 | 40 | 110 | 500 | 4050*1750*2380 | 5800 | ||||||||||||||||||||||||
| RKL-12/40 | 12 | 40 | 132 | 580 | 4050*1750*2380 | 6000 | ||||||||||||||||||||||||
| RKL-16/40 | 16 | 40 | 160 | 390 | 4650*2200*2780 | 7400 | ||||||||||||||||||||||||
| RKL-18/40 | 18 | 40 | 185 | 440 | 4650*2200*2780 | 7600 | ||||||||||||||||||||||||
| RKL-20/40 | 20 | 40 | 200 | 470 | 4650*2200*2780 | 7800 | ||||||||||||||||||||||||
| RKL-22/40 | 22 | 40 | 220 | 500 | 4650×2200*2780 | 8000 | ||||||||||||||||||||||||
| RKL-25/40 | 25 | 40 | 250 | 390 | 4950*2690*2980 | 8500 | ||||||||||||||||||||||||
| RKL-28/40 | 28 | 40 | 280 | 440 | 4950*2690*2980 | 8800 | ||||||||||||||||||||||||
| RKL-30/40 | 30 | 40 | 315 | 470 | 4950*2690*2980 | 9000 | ||||||||||||||||||||||||
Core Advantages
✅ Efficient and Stable: Quickly responds to pressure demands, ensuring uninterrupted production
✅ Energy-Saving: Utilizes variable frequency technology, saving 20%-30% energy compared to traditional models
✅ Oil-Free and Clean: 100% oil-free compression, preventing oil contamination of bottles (FDA/ISO certified)
✅ Intelligent Control: PLC automatically adjusts pressure to meet the production needs of different bottle shapes
✅ Low Maintenance: Modular design allows for easy filter replacement, minimizing downtime
Main Applications
Beverage Industry: Mineral water bottles, carbonated beverage bottles, and juice bottles
Daily Chemical Packaging: PET packaging for shampoo, shower gel, and other products
Food Packaging: Blow molding of cooking oil and condiment bottles
Pharmaceutical Packaging: Aseptic blow molding of oral liquid and medicine bottles
FAQ
Q1: What pressure is required?
A: Typically 25-40 bar, depending on preform size and mold design.
Q2: Is oil-free air required?
A: Yes. Food- and pharmaceutical-grade PET bottles require oil-free air to avoid contamination.
Q3: How do you ensure dry air?
A: A refrigerated or adsorption dryer with a dew point of ≤-40°C is required.
Q4: How many blow molding machines can one machine power?
A: It depends on the compressor flow rate (e.g., a 110kW model can support 2-4 dual-mode blow molding machines).
Q5: What is the maintenance interval?
A: The primary filter element should be replaced every 500 hours, and the fine filter element every 2000 hours.
