The Hanbell AA-2600 is a single-stage screw air compressor block (air end) from Hanbell's AA series, designed for standard pressure applications (8 bar.g). Operating at 2950 rpm, it delivers an airflow of 40.7 m³/min with a shaft power of 260.6 KW and specific power consumption of 6.4 kw/m³/min . This robust unit is engineered for heavy-duty industrial compressed air systems requiring reliable performance.
Technical Parameters
| Model | Power (kW) | Rotating speed (rpm) | Air Delivery (m3/min) | Shaft power (kW) | Specific power (kW/m3/min) | S.F. | Dimension(mm) | Weight(kg) |
| AA-2600 | 250 | 2950 | 40.7 | 260.6 | 6.4 | 1.04 | 1000 * 700 * 550 | 900 |
AA-2600 screw air end Advantages
Long Service Life & Excellent Stability–Precision-engineered with high-quality bearings and rotors, ensuring reliable operation over extended periods .
15+ Years Market Validation–AA series has been used in the market for over 15 years with proven performance and good reputation, benchmarking against international brand heads .
High Application Pressure–Capable of handling demanding pressure requirements while maintaining efficiency .
Optimized Energy Efficiency–With specific power consumption of 6.4 kw/m³/min at 8 bar, it delivers competitive efficiency for its class .
Rugged Construction–Built with one-piece shell structure to minimize internal pressure loss and ensure structural integrity .
Easy Assembly Integration–Designed for straightforward installation into compressor packages, reducing manufacturing complexity.
FAQ
1. What is the standard operating speed for AA-2600?
The AA-2600 is designed for 2950 rpm operation (50Hz applications), delivering rated performance at this speed .
2. What maintenance does the AA-2600 require?
Regular oil changes (every 3000 hours), air filter inspections, and bearing condition monitoring. Major bearing replacement is typically recommended around 20,000 operating hours .
3. What are the typical applications?
Ideal for industrial manufacturing plants, automotive facilities, food processing, and general industrial applications requiring reliable 37-45KW class compressed air systems.
4. Can the AA-2600 operate at different pressures?
While primarily designed for 8 bar applications, performance at other pressures should be verified with Hanbell technical documentation for optimal efficiency and reliability .
5. Is the AA-2600 suitable for continuous 24/7 operation?
Yes, with proper maintenance and lubrication, the AA-2600 is designed for continuous industrial duty cycles.
