Key Features
1.High pressure ratio with multi-stage compression and intercooling.
2.Robust construction for high-pressure components (e.g., cylinders, seals).
3.Automated control with safety valves and pressure/temperature monitoring.
4.Energy-efficient design, suitable for continuous operation.
5.Compact and modular for easy integration.
Advantages
Converts low/medium-pressure nitrogen into high pressure reliably.
Low operating cost and minimal maintenance.
Ensures stable output for precision applications.
Enhances productivity in high-pressure testing and processes.
Technical Parameters
| Model | Inlet P (Mpa) | Outlet P (Mpa) | Capacity (Nm3/h) | Motor Power (kW) | Dimensions L*W*H(mm) | Compression | Inlet size | Outlet Size | Weight (kg) |
| RSWN-100/5-50 | 0.5 | 5 | 100 | 15 | 1500x800x1250 | 2 | Rc1 | Rc1/2 | 480 |
| RSWN-120/5-50 | 0.5 | 5 | 120 | 18.5 | 1500x850x1250 | 2 | Rc1 | Rc1/2 | 510 |
| RSWN-140/5-50 | 0.5 | 5 | 140 | 22 | 1500x850x1250 | 2 | Rc1 | Rc1/2 | 540 |
| RWWN-160/5-50-II | 0.5 | 5 | 160 | 15x2 | 1600x1600x1200 | 3 | Rc1 | Rc1/2 | 1000 |
| RSWN-200/5-50-II | 0.5 | 5 | 200 | 15x2 | 2800x1300x1250 | 2 | Rc11/2 | Rc1/2 | 1250 |
| RSWN-240/5-50-II | 0.5 | 5 | 240 | 18.5x2 | 2800x1300x1250 | 2 | Rc11/2 | Rc1/2 | 1300 |
Applications
Pressure testing (pipes, valves, vessels)
Automotive & aerospace components testing
Gas injection & charging (e.g., nitrogen springs, accumulators)
Explosive atmosphere simulation
Chemical processing & pneumatic tool systems
FAQ
Q: Can it use compressed air instead of nitrogen?
A: Designed for nitrogen，using air requires checking material compatibility and safety.
Q: How often is maintenance needed?
A: Seals and filters should be checked every 500–1000 hours; varies with operation intensity.
Q: Does it need an external cooling system?
A: Intercoolers are usually built-in, for intensive use, additional cooling may be recommended.
Q: Can it run continuously?
A: Yes, if designed for duty cycle operation and with proper cooling.
Q: How to choose the right flow rate (Nm³/h)?
A: Determine based on demand at 50 bar, consider peak usage and future expansion.
