Features & Benefits
1. Designed for oxygen service with oil-free compression and compatible materials to ensure safety and purity.
2.Boosts inlet pressure from 5 bar to 50 bar with a flow rate of 30 Nm³/h, suitable for medium-to-high pressure applications.
3. Energy-efficient and reliable, featuring robust construction and low maintenance requirements.
4.Enhances process stability and productivity in oxygen-dependent industries.
Technical Parameters
| Model | Inlet P (Mpa) | Outlet P (Mpa) | Capacity(m3/h) | Motor Power(Kw) | Dimension L*W*H(mm) | Compression | Inlet size | Outlet Size | Weight (kg) |
| RVWN-20/5-50 | 0.5 | 5 | 20 | 4 | 1250x550x900 | 2 | Rc1/2 | Rc1/2 | 230 |
| RWWN-30/5-50 | 0.5 | 5 | 30 | 5.5 | 1350x600x1200 | 3 | Rc1 | Rc1/2 | 320 |
| RWWN-40/5-50 | 0.5 | 5 | 40 | 7.5 | 1350x600x1200 | 3 | Rc1 | Rc1/2 | 350 |
| RWWN-50/5-50 | 0.5 | 5 | 50 | 11 | 1350x700x1200 | 3 | Rc1 | Rc1/2 | 380 |
| RWWN-60/5-50 | 0.5 | 5 | 60 | 11 | 1350x700x1200 | 3 | Rc1 | Rc1/2 | 380 |
| RWWN-70/5-50 | 0.5 | 5 | 70 | 11 | 1350x700x1200 | 3 | Rc1 | Rc1/2 | 380 |
| RWWN-80/5-50 | 0.5 | 5 | 80 | 15 | 1350x700x1200 | 3 | Rc1 | Rc1/2 | 410 |
| RSWN-100/5-50 | 0.5 | 5 | 100 | 15 | 1500x800x1250 | 2 | Rc1 | Rc1/2 | 480 |
Applications
Medical oxygen supply systems
Metal cutting & welding (laser/oxy-fuel)
Aerospace & submarine life support
Wastewater treatment & ozone generation
Chemical oxidation processes
FAQ
Is it safe for oxygen use?
Yes. It uses oil-free design, oxygen-compatible materials, and complies with strict safety standards to prevent fire risks.
Can it be used for other gases?
No. It is configured specifically for oxygen. Using other gases may cause safety or performance issues.
What maintenance is required?
Regular inspection of seals and filters, with no oil changes needed. Ensure inlet air is clean and dry.
What if inlet pressure varies?
Stable inlet pressure (around 5 bar) is recommended. Significant drops may reduce output pressure and flow.
