Compared to traditional compressors, the oil-free scroll type offers exceptional performance with a novel structure, compact size, light weight design, low noise levels, long lifespan, and reduced maintenance costs. Known for its minimal maintenance requirements, it is the ideal solution for air compressors up to 75HP.
Product Parameters
| Oil free scroll air compressor | |||||||||
| Model | Air Delivery(m3/min) | Power (kW) | Air-end | Air tank | Noise dB(A) | Outlet diameter | Dimension (mm) | Weight (Kg) | |
| 8bar | 10bar | Power*Qty | Liters | L * W * H | |||||
| RO-22A | 2.40 | 2.20 | 22 | 5.5*4 | / | 63 | G1 1/2 | 1565*1274*1330 | 730 |
| RO-33A | 3.60 | 3.30 | 33 | 5.5*6 | / | 65 | G1 1/2 | 1565*1274*1775 | 1020 |
| RO-44A | 4.80 | 4.40 | 44 | 5.5*8 | / | 68 | G1 1/2 | 1565*1274*1775 | 1250 |
Technical Advantages
Fully Oil-free
Certified as Class O oil-free by the German TÜV organization, ensuring a 100% oil-free operation for optimal air purity and reliability.
Low Noise Operation
Designed with advanced vibration and noise reduction technology, ensuring smooth, consistent airflow with minimal noise and low vibration.
Reduced Vibration
The high-pressure distribution around the axis is uniform, eliminating eccentricity and ensuring optimal balance. This design effectively minimizes vibration for smooth and stable operation.
Intelligent and Reliable
Equipped with multi-stage scroll airends, the system automatically adjusts the scroll units based on air demand. In the event of a failure,the independent control of each unit ensures that overall system performance remains unaffected.
Typical Applications
1. Healthcare Industry
• Hospitals and Clinics: Provides pure compressed air for ventilators, dental equipment, surgical instruments, and more, eliminating the risk of oil contamination.
• Laboratories: Used for precision instruments and pneumatic tools, ensuring an oil-free laboratory environment.
2. Food and Beverage Industry
• Food Processing: Provides oil-free air for packaging, filling, and mixing, complying with food safety standards (such as ISO 22000 and HACCP).
• Beverage Production: Used for bottling and pneumatic conveying, preventing oil from affecting product taste or safety.
3. Pharmaceutical and Biotechnology Industry
• Pharmaceutical Manufacturing: Ensures air cleanliness (in compliance with GMP certification requirements) during processes such as tablet pressing, packaging, and fermentation.
• Biological Laboratories: Used for incubators and aseptic processing equipment.
