This energy-saving air compressor uses water instead of oil to lubricate the screw, is driven by a permanent magnet motor and has a variable frequency adjustment function, and outputs 100% oil-free compressed air.
Features
Oil-free and environmentally friendly
Water lubrication and pure compressed air (Class 0) eliminate the risk of oil contamination.
Energy-efficient
Permanent magnet motor + variable frequency technology saves 30%-50% more energy than standard frequency motors.
Low maintenance
The water circulation system reduces mechanical wear and extends life.
Low noise
The water medium reduces noise for quieter operation.
Application Scenarios
High-purity requirements: Food, pharmaceutical, electronics, photovoltaic, and other manufacturing industries.
Energy-saving scenarios: Long-term continuous operation requiring variable frequency drive control.
Harsh environments: High temperatures, flammable and explosive environments (water lubrication eliminates the risk of explosion).
Product Parameters
| Oil-free Water Lubricated Screw Air Compressor RW Series | |||||||||||
| Model | Air Delivery (m3/min) | Power (kW) | Lubricating water amount (Liters) | Cooling water amount T/Hour | Cooling water inlet/outlet diameter | Noise dB(A) | Outlet diameter | Dimension (mm) | Weight (Kg) | ||
| 8 bar | 10 Bar | 12.5 bar | L*W*H | ||||||||
| RW-30A/W | 5.12 | 4.43 | 3.63 | 30 | 40 | 7.0 | 1 1/2" | 67 | 1 1/4" | 1550*1150*1550(A) 1500*1150*1300(W) | 1100 |
| RW-37A/W | 6.30 | 5.33 | 4.77 | 37 | 40 | 9.0 | 1 1/2" | 67 | 1 1/4" | 1550*1150*1550(A) 1500*1150*1300(W) | 1150 |
FAQ
1. Water quality requirements?
Softened or deionized water is required to prevent scaling and corrosion.
2. Is maintenance cost high?
Lower than oil-fired compressors (eliminating oil changes and oil filtration costs), but regular water system cleaning is required.
3. Can it replace oil-fired air compressors?
It is suitable for clean environments; special models are required for high-temperature and high-pressure conditions.
4. Energy efficiency?
The variable frequency drive + permanent magnet motor offers significant energy savings at partial loads.
5. Disadvantages?
The initial investment is high, and antifreeze measures are required in low-temperature environments.
