An air booster is a device that uses pneumatic or hydraulic principles to amplify the pressure of ordinary factory air sources (such as 0.6-0.8 MPa) several times, outputting ultra-high pressure air (up to tens to hundreds of megapascals). Essentially, it is a pressure converter, not a traditional air compressor.
Features and Advantages
1. Extremely High Output Pressure
A core advantage, easily achieving ultra-high pressures unattainable by ordinary air compressors.
2. Energy Saving and Economical
Requires only a small amount of driving air to generate high-pressure output, eliminating the need for an expensive high-pressure main air compressor.
3. Safe and Explosion-Proof
Purely pneumatically driven, generating no electrical sparks, making it particularly suitable for flammable and explosive environments.
4. Simple Maintenance
Cmpact structure, few components, and high reliability.
Product Parameters
Model | Intake pressure (bar) | Discharge Pressure (bar) | Free Air delivery （m³/min） | Motor power （kW） | Speed (rpm) | Dimensions (mm) | Weight （kg） |
| RKBW-5/10-40 | 10.0 | 40.0 | 5 | 22 | 680 | 2300*1580*1920 | 1600 |
| RKBW-10/10-40 | 10.0 | 40.0 | 10 | 45 | 690 | 2750*1580*1600 | 2000 |
| RKBW-12/8-40 | 10.0 | 40.0 | 12 | 45 | 690 | 2750*1580*1600 | 2000 |
| RKBW-15/10-40 | 10.0 | 40.0 | 15 | 55 | 690 | 2750*1580*1950 | 2250 |
Applications
• Air tightness testing
High-pressure leak testing of valves, pipes, and automotive parts.
• Gas-assisted injection molding
Providing a stable high-pressure air source for injection molding machines.
• Localized high-pressure air source in factories
Supplying air to specific tools or equipment (such as pneumatic presses and riveting tools).
• Aerospace
Simulating high-altitude environments to test the pressure resistance of components.
FAQs
Q: What's the difference between it and a high-pressure air compressor?
A: An air compressor "manufactures" compressed air; a booster compressor "increases" the pressure of existing compressed air, used as a localized pressure boosting device.
Q: What conditions are required to use it?
A: A basic factory air source is needed as power. Low-pressure air must be input to output high-pressure air.
Q: Is the output flow rate very small?
A: Yes. The core of a booster compressor is high pressure, not large flow rate. It is suitable for operating conditions that require stable high pressure but have low air consumption.
