The Hanbell AB-600 represents a powerful and efficient solution in the large-capacity range of air-cooled heat pump units. The "600" typically signifies a nominal cooling capacity in the range of 60 kW (or a specific model series around this capacity), indicating its design for substantial commercial and industrial applications. This model is a significant step up from smaller scroll compressor units, leveraging more powerful technology.
Technical Parameters
| Model | Power (kW) | Rotating speed (rpm) | Air Delivery (m3/min) | Shaft power (kW) | Specific power (kW/m3/min) | S.F. | Dimension(mm) | Weight(kg) |
| AB-600R | 55 | 2950 | 9.1 | 57.6 | 6.3 | 1.05 | 630*350*300 | 155 |
High-Temperature Heating Capability:
A standout feature of such units is their ability to supply hot water at significantly higher temperatures than standard scroll compressor heat pumps. The AB-600 can typically produce hot water at temperatures of 55°C to 60°C efficiently, making it suitable for a wider range of heating applications, including those designed for conventional boilers.
Advanced Microprocessor Control System:
Features a sophisticated controller with a clear interface for monitoring all critical parameters (pressures, temperatures, currents, statuses).
Comprehensive safety protection suite is standard, including: high/low pressure protection, compressor overload, phase failure/reverse protection, water flow switch protection, anti-freeze protection, and automatic defrost cycles.
BMS Integration: Standard support for communication protocols (like Modbus RTU via RS-485) is essential for a unit of this scale, allowing seamless integration into central Building Management Systems (BMS) for monitoring, alarm management, and control.
Robust and Heavy-Duty Construction:
Engineered for reliable outdoor operation in demanding environments. The chassis is constructed from heavy-gauge, corrosion-protected steel with a durable powder-coated finish.
Large, low-speed fans are often used to ensure efficient heat exchange while maintaining lower operating noise levels.
The unit is built with serviceability in mind, providing access to key components for maintenance.
Efficient Heat Exchangers:
Air-Side Coils: Utilize enhanced fin-and-tube technology (e.g., inner-grooved copper tubes, corrugated fins) to maximize heat transfer efficiency and resist fouling.
Water-Side Heat Exchanger: Employs a high-efficiency shell-and-tube design, ensuring effective heat transfer between the refrigerant and water circuit.
High Efficiency & Performance: Excels under full and partial load conditions, offering superior Energy Efficiency Ratios (EER) and Coefficients of Performance (COP) for large-scale operations.
Exceptional Durability & Longevity: Screw compressors are renowned for their robust construction, minimal vibration, and long operational life, making them ideal for 24/7 operation.
High Pressure Ratio Capability: This makes them highly effective in heating mode, capable of producing higher hot water temperatures even in moderately low ambient conditions.
Large Commercial Buildings: Large office buildings, hotels, shopping malls, supermarkets, and airport terminals (for specific zones or smaller entire buildings).
Industrial Processes: Process cooling for machinery, manufacturing plants, and providing temperature-stable environments for production or storage. Its high-temperature hot water output is useful for certain industrial heating needs.
District Heating/Cooling: Serving as the primary source for smaller district energy systems within a campus, industrial park, or multi-building complex.
Hospitals and Healthcare Facilities: Providing reliable cooling for critical areas and high-temperature hot water for space heating and domestic hot water pre-heating.
Sports Centers & Aquatic Centers: Where both pool water heating (requiring higher temperatures) and space cooling/dehumidification are needed simultaneously.
Agriculture & Aquaculture: Heating greenhouses or maintaining precise water temperatures in large-scale fish farms.
