The Hanbell AC-600R is a large-capacity, industrial-grade rotary screw air compressor designed for extreme reliability, maximum energy savings, and continuous duty in the most demanding applications. It represents the pinnacle of Hanbell's engineering for high-flow compressed air solutions.
Technical Parameters
| Model | Power (kW) | Rotating speed (rpm) | Air Delivety (m3/min) | Shaft power (kW) | Specific power (kW/m3/min) | Dimension(mm) | Weight(kg) |
| AC-600R | 55 | 3000 | 9.25 | 57.6 | 6.23 | 630*350*300 | 155 |
High-Efficiency Two-Stage Compression Air End: This is the defining feature of the "R" series. It utilizes two independent sets of rotors to compress the air in sequential stages. This design significantly reduces energy consumption, lowers discharge temperatures, and increases overall efficiency compared to single-stage compressors.
Advanced Permanent Magnet Synchronous Motor (PMSM): Often equipped with a ultra-high efficiency, low-speed PMSM motor. This type of motor offers a higher power factor, exceptional start-up torque, and superior performance across a wide range of speeds, leading to dramatic energy savings, especially in variable load conditions.
Intelligent Central Control System: Features a sophisticated PLC-based touchscreen controller for precise system management. It provides real-time monitoring of all critical parameters (pressure, temperature, energy consumption, maintenance status) and allows for advanced control strategies, including network connectivity for remote monitoring.
Optimized Cooling System: Designed with a large, corrosion-resistant cooler and an intelligent cooling fan that modulates speed based on temperature. This ensures optimal operating temperatures in any environment, maximizing performance and component life while minimizing energy wasted on cooling.
Unmatched Energy Efficiency: The combination of the two-stage compression process and the high-efficiency PMSM motor makes the AC-600R one of the most energy-efficient compressors in its class. This is its single greatest advantage, offering a very rapid return on investment (ROI) through drastically reduced electricity bills.
Superior Reliability and Uptime: The two-stage air end operates under lower mechanical and thermal stress per stage, leading to less wear and longer service life. This design, coupled with premium components, ensures maximum uptime for critical industrial processes.
Exceptional Performance Stability: The two-stage compression provides more stable air pressure output and is exceptionally effective in handling varying demand loads, ensuring consistent air quality and pressure.
Lower Total Cost of Ownership (TCO): While the initial capital investment may be higher, the dramatically lower energy costs, reduced maintenance needs, and unparalleled reliability result in a significantly lower overall cost over the compressor's entire lifecycle.
Future-Proof and Smart Connectivity: The advanced controller allows for integration into plant-wide monitoring systems, enabling predictive maintenance, data logging, and remote control, which is essential for modern smart factories.
Large Manufacturing Plants: Automotive assembly lines, heavy equipment manufacturing, and large-scale metal fabrication facilities.
Metals & Mining: Powering extensive pneumatic networks in mining operations, smelters, and mineral processing plants.
Chemical & Petrochemical Processing: Providing large volumes of reliable instrument air and process air for critical operations.
Power Generation Plants: For soot blowing, control systems, and other plant air requirements in coal, gas, or biomass power stations.
Electronics and Semiconductor Manufacturing: Where a vast, stable, and high-quality air supply is essential for production tools and automation (requires appropriate air treatment).
Large Cement and Glass Plants: Powering production processes and control systems.
