The Airend of Rocky water lubricated Oil-free screw compressor adopts PEEK door rotor, aerospace grade stainless steel rotor and a new production process. Using nano-scale water filter core and Inlet reverse osmosis system, it can provide a stable and qualified lubricating water treatment system for the compressor.
Technical Parameters
| Oil-free Water Lubricated Screw Air Compressor RW Series | |||||||||||
| Model | Air Delivery (m3/min) | Power (kW) | Lubricating water amount (Liters) | Cooling water amount T/Hour | Cooling water inlet/outlet diameter | Noise dB(A) | Outlet diameter | Dimension (mm) | Weight (Kg) | ||
| 8 bar | 10 Bar | 12.5 bar | L*W*H | ||||||||
| RW-45A/W | 7.40 | 6.30 | 5.56 | 45 | 90 | 10.0 | 1 1/2" | 68 | 2" | 1980*1300*1760(A) 1800*1300*1670(W) | 1390 |
| RW-55A/W | 9.60 | 8.55 | 7.67 | 55 | 120 | 12.0 | 1 1/2" | 70 | 2" | 1980*1300*1760(A) 1800*1300*1670(W) | 1470 |
Features
1. 100% oil-free, providing pure compressor air.
2. Simple system with fewer parts and fewer points of failure, resulting in higher reliability.
3. Low energy consumption, isothermal compression, and higher volumetric efficiency.
4. Low maintenance costs, ensuring worry-free operation.
Oil-free water-lubricated air compressors are widely used in industries such as food, medicine, electronics, chemicals, aerospace fields, semiconductors, precision spraying, biological engineering, and medical instruments.
